Fixing Docker Compose Volume Mount Performance on NFS Shares: Tuning nconnect and async Options for Database Workloads

Why I worked on this

My main Postgres database lives in a container on a Proxmox VM. The VM’s disk is already an NFS mount from the TrueNAS box in the basement (10 GbE, spinning rust, raid-z2). When I moved the container to a new host last month, every docker compose up took 90 s instead of 8 s and a simple VACUUM inside Postgres felt like it was running on a USB-1 stick. I/O wait sat at 40 % while the array downstairs was basically idle. Something in the Docker → NFS chain was clearly choking.

My real setup

• TrueNAS 13.0-U5, NFS share exported with default options (rw,no_root_squash).
• Proxmox 8.1 VM, Ubuntu 22.04, kernel 6.5, Docker 24.0.7, Compose v2.23.
• Compose snippet that mattered:

  volumes:
    pgdata:
      driver: local
      driver_opts:
        type: nfs
        o: addr=10.0.40.5,rw,nfsvers=4.2
        device: ":/mnt/pool/docker/pg14"

• Database: Postgres 14, 250 GB, mostly write-heavy telemetry.

What didn’t work

1. Single TCP connection (NFS default)
   iostat -x 1 showed only one outstanding I/O request no matter how many backends Postgres launched. Throughout capped at ~120 MB/s on a link that pushes 600 MB/s with dd.
2. Synchronous writes (default mount)
   Every COMMIT waited for the server to flush ZFS to spinning disks. pg_test_fsync reported 250 fsync/s — the same number I got when I accidentally ran Postgres on a USB key in 2014.
3. Cache-dropping "benchmarks"
   I tried echo 3 > /proc/sys/vm/drop_caches between runs to get “clean” numbers. All it did was make the database cold and angry; production performance never looked like those numbers anyway.

What worked (and why)

1. Enable multiple TCP connections with nconnect

Linux 5.3+ and NFS 4.1+ support the nconnect mount option. It stripes one NFS session over several TCP flows. I raised the count until throughput stopped growing; 4 turned out to be the sweet spot on my 10 GbE link.

o: addr=10.0.40.5,rw,nfsvers=4.2,nconnect=4

After a docker compose down && docker compose up the same VACUUM finished in 11 min instead of 47 min. iostat now showed 4–6 outstanding requests and 450–500 MB/s read bursts.

2. Allow asynchronous commits with async

My UPS keeps the VM alive for 20 min; losing the last second of writes is acceptable. I added async to the mount so the server can acknowledge writes as soon as they hit RAM, not rust.

o: addr=10.0.40.5,rw,nfsvers=4.2,nconnect=4,async

pg_test_fsync jumped to 12 000 fsync/s — still not local-SSD territory, but 48 × better than before. Application latency (p95) dropped from 42 ms to 9 ms under a simulated 1 000 inserts/sec load.

3. Keep Postgres settings honest

I left wal_level = replica and fsync = on inside the container; the safety switch is the NFS layer, not the database. If you run async on the server side, fsync = off inside Postgres is redundant and dangerous.

4. Re-export the share read-only for backups

Another VM needs nightly pgBackRest. I created a second TrueNAS share of the same dataset read-only and mounted it ro,nolock on the backup VM. That avoids contention and keeps me from accidentally typing DROP in the wrong place.

Key takeaways

• NFS 4.2 with nconnect gives almost linear throughput scaling up to the wire speed—if the disk array can feed it.
• async on the server side is the cheapest latency win you can get, but only when you already trust your power and your replication.
• Docker Compose volume driver options are passed straight to the kernel; anything you can put in mount -t nfs -o … works here too.
• Measure with the real workload, not with dd. My 120 MB/s “limit” vanished only when Postgres itself issued parallel reads.
• Document the mount string somewhere outside the compose file; the next panic reboot will wipe it from memory.

I still wouldn’t run a latency-critical trading database over this stack, but for my telemetry and home-lab services the tuning above turned “unusable” into “good enough that I stopped thinking about it.”
